In-Line Pilot Check Valve – Barrel Type
| Part Number | Max Flow (L/min) | Max Pressure (bar) | A (mm) | B (mm) | C (BSP) | X (BSP) | E (mm) |
|---|---|---|---|---|---|---|---|
| CV 0400 | 12 | 350 | 103 | 36 | 1/4 | 1/4 | 11 |
| CV 0600 | 30 | 310 | 109 | 40 | 3/8 | 1/4 | 11.5 |
| CV 0800 | 45 | 310 | 120 | 42 | 1/2 | 1/4 | 11 |
| CV 1200 | 85 | 300 | 131 | 55 | 3/4 | 1/4 | 14 |
